Global Fire ZEOS Portable Addressable Device Programmer (GFE-ZEOS-PROGRAMMER)

The Global Fire Equipment GFE-ZEOS-PROGRAMMER is a handheld portable programmer for GFE self-programmable addressable devices. It lets installers and service engineers manually assign device addresses during installation and maintenance, as an alternative to the ASET mode of GFE addressable control panels. It can also read back a device's address and its analogue value. The programmer runs on a rechargeable lithium battery, charged via its mini USB port.

Key features

• Manual address assignment for GFE self-programmable addressable devices
• Reads the current address and the analogue value of a device
• Alternative to the control panel's ASET mode during installation and maintenance
• Rechargeable lithium battery, charged via mini USB
• Simple keypad: OK (power on / program address), UP/DOWN (change address), UP+OK (read analogue value), UP+DOWN (read address)
• Status LED: green (working), flashing green (charging), yellow (function in progress), red (internal fault), flashing red (low battery)
• Auto power off after 2 minutes

Technical specifications

• Order code: GFE-ZEOS-PROGRAMMER
• Operating voltage: 3.3V DC
• Charge voltage: 5V DC (mini USB)
• Charge current: 100mA max.
• Charge time: 2 hours max.
• Autonomy: 500+ operations per charge
• Auto power off: after 2 minutes
• Operating temperature: 0°C to 40°C
• Max. humidity: 95% RH non-condensing
• Dimensions: 86 mm (D) x 25 mm (H)
• Weight: 172 g
