Hochiki HCP-E(BLU)-SCI Addressable Manual Call Point with SCI (Blue)

The Hochiki HCP-E(BLU)-SCI is the blue version of the HCP-E(SCI) intelligent manual call point, fully compatible with Hochiki's ESP analogue addressable protocol. It has an integral short-circuit isolator and a bi-coloured status LED.

The LED can be set to pulse for communications polling and lights continuously red when operated, or amber when a short-circuit is present. Hochiki notes that only the red casing carries LPCB approval.

Key features

• Integral short-circuit isolator
• Bi-coloured LED: red for polling/alarm, amber when a short-circuit is present
• Fast response
• Non-frangible element fitted as standard; optional glass element available
• Built-in test function initiated by the control panel, plus test-key testing from the underside
• Two terminal blocks for easy loop connection
• Addressed with the TCH-B200 hand held programmer
• Flush mounting as supplied; surface mounting with the SR MOUNTING BOX (sold separately)

Technical specifications

• Ordering code: HCP-E(BLU)-SCI (blue casing)
• Protocol: Hochiki ESP (digital communication)
• Operating voltage: 17 to 41 VDC
• Low power mode: 180 µA max, 100 µA typical
• Quiescent current: 350 µA max, 250 µA typical
• Alarm current: 10.0 mA max, 5 mA typical
• Short-circuit threshold (typical): 430 Ω
• Ingress protection: IP24
• Case material: modified polyphenylene oxide
• Operating temperature: -10 °C to +50 °C
• Storage temperature: -30 °C to +70 °C
• Maximum humidity: 95% RH, non-condensing (at 40 °C)
• Weight / dimensions (flush): 110 g / W 89 x H 93 x D 27.5 mm
• With surface-mount back box: 161 g / W 89 x H 93 x D 59.5 mm
