The Nittan EV1-BK-BOX is the replacement enclosure back box for the Nittan evolution 1 single-loop touch screen fire alarm control panel (F12-83101). It is the wall-mounted rear part of the ABS enclosure that houses the panel electronics and standby batteries.
The back box fixes to the wall through three mounting holes (two round holes near the bottom and a keyhole near the top), designed for No. 8 round-head or countersunk woodscrews. The top face has knockout cable entries, with mains entering at the top right.
Key features
- Genuine Nittan replacement part for the evolution 1 panel
- Three-point wall fixing (two holes plus keyhole)
- 15 top knockout cable entries, no bottom entries
- Space for 2 x 7 Ah standby batteries
Technical specifications
- Enclosure size: W 370 x H 311 x D 113 mm
- Cable entries: 15 top, 0 bottom
- Enclosure rating: IP30 (indoor use)
- Material: ABS
- Battery space: up to 2 x 7.0 Ah 12 V sealed lead acid
- For use with: Nittan evolution 1 panel (F12-83101)
