| Application/Usage |
Network PoE devices such as wireless access points, IP cameras, VoIP phone systems, IPTV decoders, access controls |
| Compatibility |
Cat5e or better cabling; Non-PoE switch; PoE (15.4W), PoE+ (30W) or PoE++ (90W) devices |
| Data Transfer Rate |
3Gbps |
| Depth |
73.0mm |
| Features |
2.5GBASE-T compliant; Auto-sensing technology; Converts a non-PoE 2.5G port to a PoE++ 2.5G port; IEEE 802.3af, 802.3at and 802.3bt compliant; Integrated power supply; Network a PoE device up to 100m (328 ft.); Plug and Play installation; Sturdy metal housing; Supplies PoE (15.4W), PoE+ (30W) or PoE++ (90W); Wall-mount design |
| Height |
36.0mm |
| Input Ports |
1 x 2.5G RJ-45 port (data) |
| Input Voltage |
100-240V AC |
| Limited Warranty |
3-Year |
| Material |
Metal |
| Mount Type |
Wall Mount |
| Number of Network (RJ-45) Ports |
2 |
| Output Ports |
1 x 2.5G RJ-45 PoE++ port (data + power out) |
| Package Contents |
Power cord (1.5m / 4.9 ft.); Quick Installation Guide; TPE-219GI |
| PoE (RJ-45) Port |
Yes |
| PoE Budget |
90W |
| Power Consumption |
1W |
| Product Series |
Version V1 |
| Product Type |
Power Injector |
| Weight |
386.00g |
| Width |
154.0mm |
| CE Marking |
Yes |
| Certifications & Standards |
CE; ETL; FCC |
| Dimensions |
154mm x 73mm x 36mm |
| LED Indicator |
Status |
| Maximum Input Current |
1A |
| Maximum Transfer Distance |
100m |
| Networking Standards |
IEEE 802.3; IEEE 802.3ab; IEEE 802.3af; IEEE 802.3at; IEEE 802.3bt; IEEE 802.3bz; IEEE 802.3u |
| Number of Ethernet Ports |
2 |
| Operating Relative Humidity (H-H) |
90% (Non-condensing) |
| Operating Temperature (T-T) |
0-40°C |
| Power over Ethernet (PoE) |
Yes |
| RoHS Compliant |
Compliant |
| WEEE Compliant |
Out of Scope |
