Zeta Infinity8 1 Zone Conventional Fire Alarm Panel (IN1)

The Zeta Infinity8 IN1 is a 1-zone conventional fire alarm control panel. It is housed in an attractive, modern, flame-retardant ABS enclosure with a switch-mode power supply, and has a fully removable front cover for easier cable installation.

It meets the requirements of EN 54-2 and EN 54-4 and works with conventional detectors such as Zeta's Fyreye MKII range. A version with a metal back box, which takes up to 7 Ah batteries, can be ordered by adding /M to the model number.

Key features

• Access by password, removing the problem of lost keys
• One-man test facility
• Disablement facility for zones and sounders
• Sounder delay option
• 2 sounder circuits
• Space for up to 3 Ah batteries
• Meets EN 54-2 and EN 54-4

Technical specifications

• Model / part no.: IN1 (37-650)
• Zones: 1
• Mains supply: 230 V AC +10% / -15% at 50/60 Hz
• System voltage: 24 V DC nominal; zone voltage 21 V DC nominal
• Sounder outputs: 2 x 150 mA at 24 V DC
• Fault relay: volt-free, SELV at 1 A max.
• Zone capacity: 32 devices per zone
• Sounder activation delay: 0-10 minutes in 1-minute steps
• Zone end of line: 1N4002 diode; sounder end of line: 10k resistor
• Charger voltage: 27.6 V
• Batteries: 2 x 12 V sealed lead acid, up to 3.4 Ah
• Enclosure: 371 x 302 x 93 mm; weight 3 kg (excluding batteries)
• Kitemark KM 575040; CPR 2797-CPR-670814
