The Advanced EXP-003-065 is a HOLD switch in an IP65-rated plastic enclosure for surface mounting, for use with ExGo gas extinguishing and suppression control panels. Wired to an ExGo panel or Remote Status Indicator input circuit, it lets staff hold (pause) the extinguishing release sequence as programmed on the panel.
The switches meet the requirements of BS 7273-1, are simple to wire, and several units can be daisy-chained on one input circuit. Each unit is supplied with an end-of-line resistor.
Key features
- IP65-rated enclosure, surface mounted
- Complies with BS 7273-1
- Multiple units can be daisy-chained on one input circuit
- Supplied with end-of-line resistor
- Compatible with ExGo gas extinguishing panel and Remote Status Indicator input circuits
Technical specifications
-
Dimensions: 72 x 72 x 62mm overall (including switch actuator)
-
Function: HOLD
-
End-of-line resistance: 6800 ohms
-
SW#1 active resistance: 470 ohms
-
Maximum operating voltage: 30V DC
-
Environment: Indoor, 0°C to 40°C
-
Humidity: 95% max
-
Standard: BS 7273-1
