Key featuresFull details
- 4 individually programmable relay outputs
- Each output rated 230V, 5A
- Outputs synchronised and fully programmable via cause and effect
- Up to 16 cards per multi-loop panel (64 outputs)
- Input to monitor the fault output of a power supply
- Configured via PC-NeT
Frequently bought together
Advanced
Advanced MXP-047 ESPA Pager interface
Sale price£943.50
Out of stock. Lead time 2 to 6 weeks, estimate only
Product details
The Advanced MXP-035F is the MxPro 5 Programmable 4-Way Relay Card, supplied fitted to the panel. It adds four individually programmable relay outputs to an MxPro 5 control panel, connected via the P-Bus.
Each output can be assigned to its own output group and programmed with any of the dynamic cause-and-effect rules in the MxPro 5 configuration, making it suitable for plant control and signalling. Up to 16 cards can be connected to a multi-loop panel for up to 64 additional relay outputs. Fitting this card in a panel precludes fitting other panel option cards.
Key features
- 4 individually programmable relay outputs
- Each output rated 230V, 5A
- Outputs synchronised and fully programmable via cause and effect
- Up to 16 cards per multi-loop panel (64 outputs)
- Input to monitor the fault output of a power supply
- Configured via PC-NeT
- 3-year warranty as standard
Technical specifications
- Part code: MXP-035F
- Outputs: 4 x 230V AC 5A resistive / 230V AC ½ HP / 30V DC 5A
- Supply: 24V DC nominal (18-28V); 22mA quiescent, 75mA outputs on
- PCB dimensions (H x W x D): 100 x 86 x 16mm
- PCB LED indications: Relay circuit on, communications TX and RX, heartbeat
- Standards: BS EN 54-2, BS EN 54-4
- Compatibility: All MxPro 5 control panels
