The Advanced MXP-503F is the MXP-503 Standard Network Card supplied fitted to an MxPro 5 control panel. Adding a network card lets MxPro 5 control panels, remote terminals and network peripherals be linked using standard fire-resistant two-core cable, as a true peer-to-peer network.
Information from any input or output device can be passed across the network and displayed on any MxPro 5 panel or remote terminal, and cause and effect can link any input device to any output device on any panel. Other nodes recognise a panel as soon as it is given a valid network address, so panels can be added at any time. For larger or fault-tolerant networks, Advanced offers the MXP-509 Fault Tolerant Network Card.
Key features
- Peer-to-peer networking for MxPro 5 panels and remote terminals
- Uses standard fire-resistant two-core cable
- Network analyser on every panel for diagnostic and status information
- Transmission of fires or faults can be blocked during commissioning
- Sector-based programming of Mute, Silence, Resound and Reset with PC-NeT Mx configuration software
- TX and RX indicator LEDs on the card
- Supplied fitted to the panel
Technical specifications
-
Card type: MXP-503 Standard Network Card (fitted)
-
Network connections: IN: A/B/SCN (screen); OUT: A/B/SCN (screen)
-
On-board indication: 2 red LEDs (data transmitted, data received)
-
Supply current: 20mA, taken from the panel motherboard
-
Maximum total cable length: 1.5km
-
Maximum network nodes: 32 (50 with signal buffer)
-
Recommended cable: 2-core twisted pair plus screen
-
Temperature: -5°C to 40°C
-
Humidity: 95% non-condensing max
-
Dimensions (H x W x D): 85 x 65 x 20mm
