Advanced MXP-635-MM Fibre Optic SFP Module - Multi Mode
SKU: MXP-635-MMBrand: Advanced
| Out of stock | Qty | Delivery |
|---|---|---|
| All locations | 0 | Lead time 2 to 6 weeks, estimate only |
Need help choosing?
Our UK team can check compatibility, stock and project pricing for you.
0113 518 0540info@jemsystems.co.uk
Advanced MXP-635-MM Fibre Optic SFP Module - Multi Mode
£136.30
Genuine stockBrand new, boxed
1 year warrantyPlus statutory rights
Secure checkoutEncrypted payments
Trade accounts30 day credit
Key featuresFull details
- Multi-mode fibre, up to 2km
- Hot-pluggable, duplex LC connector
- Operating data rates up to 1.25Gbps
- 1310nm FP laser transmitter
- Ultra-low power; single 3.3V supply with TTL logic interface
- Digital Diagnostic Monitoring (DDM) and Digital Optical Monitoring (DOM)
Frequently bought together
Advanced
Advanced MXP-635-P Fibre Optic Convertor - Passive
Sale price£1,265.50
Out of stock. Lead time 2 to 6 weeks, estimate only
Advanced
Advanced MXP-635-SM Fibre Optic SFP Module - Single Mode
Sale price£136.30
Out of stock. Lead time 2 to 6 weeks, estimate only
Advanced
Advanced MXP-650 2.5A 24V EN54-4 PSE & Battery Charger - Large (up to 2x 17Ah batteries)
Sale price£234.30
In stock
Advanced
Advanced MXP-650/D 2.5A 24V EN54-4 PSE & Battery Charger - Deep (up to 2x 24Ah or 38Ah batteries)
Sale price£295.95
Out of stock. Lead time 2 to 6 weeks, estimate only
Advanced
Advanced MXP-651 5.0A 24V EN54-4 PSE & Battery Charger - Large (up to 2x 17Ah batteries)
Sale price£367.05
Out of stock. Lead time 2 to 6 weeks, estimate onlyProduct details
The Advanced MXP-635-MM is a multi-mode Small Form-factor Pluggable (SFP) fibre optic transceiver for the Advanced MXP-635-A (active) and MXP-635-P (passive) fibre optic converters. It allows network communications up to 2km over multi-mode fibre between fibre optic converters on MxPro 5 networks.
The module includes an enhanced Digital Diagnostic Monitoring (DDM) interface, compliant with SFF-8472, giving real-time access to its operating parameters: SFP temperature, laser bias current, transmitted and received optical power, and supply voltage.
Key features
- Multi-mode fibre, up to 2km
- Hot-pluggable, duplex LC connector
- Operating data rates up to 1.25Gbps
- 1310nm FP laser transmitter
- Ultra-low power; single 3.3V supply with TTL logic interface
- Digital Diagnostic Monitoring (DDM) and Digital Optical Monitoring (DOM)
- Conformal coating for harsh environments
- Class 1 laser to IEC 60825
- Compliant with SFP MSA and SFF-8472
Technical specifications
- Fibre type: Multi-mode
- Maximum distance: 2km
- Data rate: Up to 1.25Gbps
- Transmitter: 1310nm FP laser
- Receiver: PIN photodiode with trans-impedance preamplifier (TIA)
- Connector: Duplex LC
- Power supply: Single 3.3V
- Operating case temperature: 0°C to +70°C
- Approvals: CE, UKCA, RoHS, WEEE; EMC EN 61000-6-2 and EN 61000-6-4; safety EN 60950
- For use with: MXP-635-A and MXP-635-P fibre optic converters
