The Ceasefire Mini Intuitive CF-001339A is a 100g automatic micro-environment fire suppression unit filled with the clean agent Fluoroketone (FK-5-1-12), in a red stainless steel shell with a 57°C quartzoid bulb. It is placed inside, or fixed to the inner wall of, a small enclosed space such as a server cabinet or fuse box and protects it from within: when the bulb reaches its rated temperature it breaks and the agent discharges automatically, with no power supply or human intervention. FK is a cold gas that extinguishes fire by absorbing heat, and leaves no residue.
Key features
- Fully automatic detection, actuation and suppression
- Mechanical release: no power supply needed
- Clean agent FK-5-1-12 leaves no residue and will not damage electronics
- For Class A, B, C and electrically started fires
- Fluoroketone falls outside the F-Gas Regulations
- Magnetic Bourdon tube pressure gauge
- Stainless steel 316L shell
Technical specifications
-
Product code: CF-001339A
-
Agent: Fluoroketone (FK-5-1-12), stored pressure
-
Capacity: 100g
-
Actuation temperature: 57°C
-
Minimum discharge time: 1 to 3 seconds
-
Discharge fitting: Direct nozzle
-
Coverage volume: 0.130m³
-
Filled weight: Approx. 0.665kg
-
Shell: Stainless steel 316L (1.4435), minimum wall thickness 1.2mm, red RAL 3000
-
Shell diameter: 40mm
-
Height: Approx. 184mm
-
Service pressure: 10 / 12 bar
-
Test pressure: 35 bar
-
Warranty: 5 years
-
Certification: PED, UKCA-PED, BSI tested
