HAES Esento Marine Approved 8 Zone Conventional Fire Panel (ESEN-8MAR)

The HAES Esento Marine ESEN-8MAR is an 8 zone marine approved conventional fire alarm control panel. Esento Marine control panels are approved by MED, Lloyd's Register and ABS for use in all seafaring vessels.

It offers muster alarm zone settings, three false alarm management modes, output delays, networking of up to 8 control panels and fully functional repeater panels. It is compatible with Apollo Orbis Marine detectors and is also available in black (ESEN-8MAR-B).

Key features

• 8 conventional detection zones
• Marine approved: MED, Lloyd's Register and ABS
• Compatible with Apollo Orbis Marine detectors
• Network up to 8 control panels (requires network card)
• Muster alarm feature, selectable per zone
• Controls activated by key switch or code entry
• Integral detector removal monitoring and earth fault monitoring
• 3A switch mode power supply, nominal 27V DC
• 4 monitored sounder outputs; alarm load 2.4A shared between outputs
• 2 voltage-free changeover relays (1 x Fire, 1 x Fault)
• Programmable delays to outputs; false alarm modes A, B and C
• Test mode with or without sounders; disable zones, sounder outputs, aux outputs and delays

Technical specifications

• Enclosure: 1.2mm mild steel, IP30, Interpon powder coat (colour ref MW334E)
• Cable entry: 20mm knockouts in the top and rear of the cabinet
• Dimensions: back box 450mm W x 300mm H x 85mm D; lid 460mm W x 310mm H x 25mm D
• Mains supply: 3A internal switch mode PSU, nominal 27V DC
• Battery capacity: 2 x 7.0Ah 12V VRSLA
• Detection zones: 8 x conventional, EOL 4K7
• Sounder circuits: 4 x monitored, fused at 500mA (resettable), EOL 4K7
• Networking: up to 8 control panels, fault tolerant RS485, requires TPCA05 network card
• On-board relays: 2 x programmable, 3A 30V volt-free changeover (additional relay on high spec zone card)
• Outputs: 2 x programmable 40mA switched -ve (2 more on high spec zone card)
• Switch inputs: class change and alert (pulsing)
• Event log: 40 events
• Intrinsically safe mode: selectable per zone
• False alarm management: type A, B and C dependency modes, LPCB approved
• Delay timer: on-board programmable, 1 to 10 minutes
• Muster alarm: selectable per zone
