Hochiki CDX Conventional "SMOKE VENT" Call Point with Backbox (Orange) (CCP-EO)

The Hochiki CCP-EO is the orange version of the CDX CCP-E conventional manual call point. It is for internal use, is based on the industry-standard KAC World Series housing and has easy-to-install push-fit wiring terminals. This listing is the version labelled "SMOKE VENT".

It is supplied with a surface-mount backbox and takes either a frangible glass element or a non-frangible plastic element. Hochiki notes that only the red CCP-E carries LPCB approval; other colours are not EN54 approved.

Key features

• Orange case
• Supplied with surface-mount backbox
• Push-fit wiring terminals accept up to 2.5 mm² solid conductor
• Supports frangible glass or non-frangible plastic elements
• Type A device

Technical specifications

• Ordering code: CCP-EO (orange)
• Nominal operating resistance: 470 Ω
• Maximum contact resistance: 200 Ω
• Maximum voltage: 30 VDC
• Current in alarm at 24 VDC: 50 mA
• IP rating: IP24D
• Operating temperature: -10 °C to +55 °C
• Storage temperature: -10 °C to +55 °C
• Maximum humidity: 93 ± 3% RH, non-condensing (at 40 °C)
• Case material: ABS
• Weight / dimensions (flush): 130 g / W 89 x H 93 x D 27.5 mm
• Weight / dimensions (surface): 180 g / W 89 x H 93 x D 59.5 mm
• Spare elements: frangible KAC/G/HE, non-frangible KAC/EWS/HE
• Colour / material: orange / ABS
