Nittan Evolution Addressable Detector Base with SC Isolator (EV-B-SCI)

The Nittan EV-B-SCI (part no. F03-83605) is a low-profile detector base with a built-in short circuit isolator, for all types of Nittan Evolution analogue addressable detectors. It is designed for dry, clean spaces, with cable entry from the centre or the side.

The -ve line isolator works transparently with no settings needed and resets itself when the fault clears. Nittan notes that +ve and -ve isolator styles cannot be mixed on one system, so check panel compatibility with Nittan technical support.

Key features

• Low profile base for all Evolution analogue detectors
• Built-in -ve line short circuit isolator
• No isolator settings required
• Self-resetting when the fault clears
• Low quiescent current
• Centre or side cable entry

Technical specifications

• Ingress protection: IP22
• Weight: 70 g
• Quiescent current: 60 µA
• Current when short-circuited: 13 mA
• Operating voltage: 22 to 38 V DC
• Operating temperature: -10°C to +55°C
• Relative humidity: 95% RH
• Cable terminals: max. 2.5 mm²
• Material: PC/ABS
• Isolator Vso min / max: 9 / 11 V DC; Vsc min / max: 10 / 12 V DC
• Isolator max. line current: 800 mA; max. switching current: 1500 mA
• Isolator max. leakage current: 13 mA; max. switch resistance: 120 mΩ
• Standard: EN 54-17:2005 / AC:2007
• Manufacturer part number: F03-83605
