| Depth |
177.80mm |
| Environmental Certification |
CE; Freefall (IEC 60068-2-32); Shock (IEC 60068-2-27); Vibration |
| Environmentally Friendly |
Yes |
| Ethernet Technology |
1 Gbps (Gigabit Ethernet) |
| Features |
1 x Gigabit port; 10Gbps switching capacity; 120W PoE power budget; 4 x Gigabit PoE ports; Hardened IP30 rated metal switch; Includes DIN-rail and wall mounts; Operating temperature range of -40 to 75 deg C (-40 to 167 deg F); Power supply sold separately (models: TI-S15052, TI-S24052, TI-S12048, TI-S24048); Redundant power inputs with overload current protection |
| Height |
76.20mm |
| Input Voltage |
48V DC; 56V DC |
| Limited Warranty |
3-Year |
| Material |
Metal |
| Media Type Supported |
Twisted Pair |
| Mount Type |
DIN Rail Mount; Wall Mount |
| NDAA Compliant |
Yes |
| Network Switch Type |
Unmanaged |
| Network Technology |
1000Base-T; 100Base-TX; 10Base-T |
| Package Contents |
- TI-PG50
- Quick Installation Guide
- Removable terminal block
- DIN-Rail and wall mount kit
|
| Plug/Connector Type |
Terminal Block |
| PoE (RJ-45) Port |
No |
| PoE Budget |
120W |
| Power Consumption |
2.2400W |
| Power Source |
AC Power |
| Product Line |
Industrial |
| Product Series |
TI |
| Product Type |
Ethernet Switch |
| TAA Compliant |
Yes |
| Total Number of Network Ports |
5 |
| Width |
101.60mm |
| Layer Supported |
2 |
| Manageable |
No |
| Manufacturer |
TRENDnet |
| Modular |
No |
| Networking Standards |
IEEE 802.3; IEEE 802.3ab; IEEE 802.3af; IEEE 802.3at; IEEE 802.3u; IEEE 802.3x |
| Power over Ethernet (PoE) |
Yes |
| Redundant Power Supply |
Yes |
| RoHS Compliant |
Compliant |
| Shared SFP Slot |
No |
| Uplink Port |
No |
| WEEE Compliant |
Compliant |
