The Zeta Simplicity CO 64 is an addressable carbon monoxide detection and ventilation control panel with 4 zones and capacity for 64 devices, supplied here in a metal enclosure. It is used in car parks, plant rooms and similar areas to monitor CO levels and switch ventilation before levels become dangerous.
Key features
- Shows the highest CO concentration in each zone in ppm on the LCD, updated every 10 seconds
- Global first ventilation, second ventilation and alarm thresholds, each individually adjustable
- Up to 2 ZIOU/I-230 interface modules can be programmed to start ventilation at set CO levels
- Raises an alarm if CO keeps rising while ventilation is running
- Devices can be wired as a single loop or as separate radial circuits
- Configurable vent/alarm relay plus a normally energised fault relay
- Individual zones can be disabled from the menus
Specification
| Product code |
S64/CO/M |
| Brand |
Zeta |
| Range |
Simplicity CO |
| Zones |
4 |
| Device capacity |
64 |
| Protocol |
Standard Zeta addressable |
| Mains supply |
230V AC +10% / -15%, 50/60Hz |
| Standby batteries |
24V DC (2 x 12V sealed lead acid) |
| Fault relay |
SELV, 1A, normally energised |
| Enclosure |
Metal |
