HAES Esento Marine Approved 2 Zone Conventional Fire Panel (ESEN-2MAR)

The HAES Esento Marine ESEN-2MAR is a 2 zone marine approved conventional fire alarm control panel. Esento Marine control panels are approved by MED, Lloyd's Register and ABS for use in all seafaring vessels.

It includes muster alarm zone settings, a false alarm management mode and non-latching zones, and is compatible with Apollo Orbis Marine detectors. It is also available in black (ESEN-2MAR-B). Note that the 2 zone panel does not support networking or repeater panels.

Key features

• 2 conventional detection zones
• Marine approved: MED, Lloyd's Register and ABS
• Compatible with Apollo Orbis Marine detectors
• Muster alarm feature, selectable per zone
• Controls activated by key switch or code entry
• Integral detector removal monitoring and earth fault monitoring
• 1.25A switch mode power supply, nominal 27V DC
• 2 monitored sounder outputs; alarm load 800mA shared between outputs
• 2 voltage-free changeover relays (1 x Fire, 1 x Fault)
• Class change and alert inputs; fire and fault switched -ve outputs
• False alarm mode; test mode with or without sounders
• Disable zones, sounder outputs and aux outputs

Technical specifications

• Enclosure: 1.2mm mild steel, IP30, Interpon powder coat (colour ref MW334E)
• Cable entry: 20mm knockouts in the top and rear of the cabinet
• Dimensions: back box 300mm W x 250mm H x 80mm D; lid 308mm W x 260mm H x 23mm D
• Mains supply: 1.25A internal switch mode PSU, nominal 27V DC
• Battery capacity: 2 x 3.2Ah 12V VRSLA
• Detection zones: 2 x conventional, EOL 4K7
• Sounder circuits: 2 x monitored, fused at 500mA (resettable), EOL 4K7
• On-board relays: 1 x Fire, 1 x Fault, 3A 30V volt-free changeover
• Switch inputs: class change and alert (pulsing)
• False alarm management: type A dependency mode, LPCB approved
• Muster alarm: selectable per zone
