Hochiki CSB-E(WHT) Conventional Sounder Base - White Case
SKU: CSB-E(WHT)Brand: Hochiki
| Out of stock | Qty | Delivery |
|---|---|---|
| All locations | 0 | Lead time 2 to 6 weeks, estimate only |
Need help choosing?
Our UK team can check compatibility, stock and project pricing for you.
0113 518 0540info@jemsystems.co.uk
Hochiki CSB-E(WHT) Conventional Sounder Base - White Case
£26.45
Genuine stockBrand new, boxed
1 year warrantyPlus statutory rights
Secure checkoutEncrypted payments
Trade accounts30 day credit
Key featuresFull details
- Robust design, easy to install
- Low current consumption
- Maximum 93 dB(A) at 1 m (tone 1)
- 32 user-selectable tones and 3 user-selectable volume levels
- Lockable cap available (CS-CAP)
- Approved to EN54 Part 3
Frequently bought together
Hochiki
Hochiki CSBB-E Conventional Sounder VID Beacon Base - Ivory Case (non EN54-23 compliant)
Sale price£70.75
Out of stock. Lead time 2 to 6 weeks, estimate only
Hochiki
Hochiki CSBB-E(WHT) Conventional Sounder VID Beacon Base - White Case (non EN54-23 compliant)
Sale price£70.75
Out of stock. Lead time 2 to 6 weeks, estimate only
Hochiki
Hochiki CWSB-E Conventional Wall Sounder VID Beacon - Red Case (non EN54-23 compliant)
Sale price£57.65
In stock
Hochiki
Hochiki CWSB-E(WHT) Conventional Wall Sounder Beacon - White Case (non EN54-23 compliant)
Sale price£57.65
Out of stock. Lead time 2 to 6 weeks, estimate only
Hochiki
Hochiki CWST-WR-S5 Conventional VAD Beacon - White Case, Red LEDs
Sale price£44.90
Out of stock. Lead time 2 to 6 weeks, estimate onlyProduct details
The Hochiki CSB-E(WHT) is a conventional base sounder in a white case, designed to complement the Hochiki CDX range of conventional detectors. It fits under a CDX detector mounted on a suitable base, and draws very little current while giving a high sound output. Tone and volume (low, medium or high) are set with DIL switches on each unit.
Key features
- Robust design, easy to install
- Low current consumption
- Maximum 93 dB(A) at 1 m (tone 1)
- 32 user-selectable tones and 3 user-selectable volume levels
- Lockable cap available (CS-CAP)
- Approved to EN54 Part 3
Technical specifications
- Ordering code: CSB-E(WHT) (white)
- Sound output at 1 m, tone 1: 86.2 dB(A) low, 87.7 dB(A) medium, 91.2 dB(A) high
- Current consumption at 24 VDC: 5.7 mA low, 7 mA medium, 9.4 mA high
- Operating voltage: 18 to 30 VDC
- Number of tones: 32
- Operating frequency: 440 to 2900 Hz
- Ingress protection: IP21C
- Operating temperature: -20 °C to +70 °C
- Compatible CDX bases: YBN-R/6, YBO-R/6PA, YBO-R/6R, YBO-R/6RN, YBO-R/6RS, YBN-R/6SK
- Compatible CDX detectors: SLR-E3N, DCD-AE3, DCD-CE3, DFJ-AE3, DFJ-CE3
- Case material: ABS
- Weight: 110 g
- Dimensions: Ø116 x 25 mm (H)
- Base fixing centres: 48 to 74 mm
- Approvals: EN54 Part 3 by LPCB and VdS on tones 1, 3, 11, 25 and 27
